Based on your electrical specifications, a magnetic powder brake or a servo motor can be used as a load to test the characteristics of the motor and motor driver.
The testing content includes torque and speed, as well as voltage (V), current (A), and power (W) of the motor driver and motor. It also encompasses the efficiency of the motor and driver, along with optional measurements such as the temperature of the motor casing and motor coils, Ld and Lq values, and back electromotive force (EMF), among others.
EV's Wheel Motor & Electric-Motorcycle Motor Test System
Hardwares:
Load Part:
Take a Servomotor or a Powder Brake
Measurement Part:
Torque Meter:
Kistler brand or Magtrol brand
Power Analyzer:
Yokogawa brand WT series
Hioki brand PW series
Low-Resistance meter: Hioki brand RM3544-01
Computer: Advantech Industrial Computer
Test items:
Simultaneously measuring each phase V, A, and Z W of input and output of the driver.
Torque, Speed, Motor- Efficiency, Drive-Efficiency, Total-Efficiency, Motor-housing Temperature (Optional), Motor-coil Temperature (Optional), Ld & Lq (Optional), Back EMF (Optional) ... and so on.
Software functions:
Providing the simulated electronic throttle control voltage for the DUT
Motor-File management: Add, Edit, Delete, Quick Search, Copy, and other functions
Data-File management: Add, Edit, Delete, Quick Search, Copy, Print, and other functions
T-N Characteristic-Curve test & Fixed-Point test & Manual test & Road simulation & Life test
Data-File can be exported to Excel format
Test data can be displayed in 6 independent curves
Characteristic-Curve can be used for comparison
(5 curves of characteristics can be drawn on the same screen)
